Load Testing in GitHub Actions

There are two practical ways to load test from GitHub Actions: run an open-source tool such as k6 directly on the runner and fail the job on thresholds, or use the workflow to trigger a hosted load test with an API token stored as a repository secret and gate on its result. Runner-based tests suit smoke tests and small performance gates on pull requests; anything that needs real load should come from outside the runner. Run a smoke test on PRs, a performance gate on main, and a longer test nightly with a cron schedule.

Two patterns, and when each fits

Both are reasonable, and many teams use both: k6 on the runner for a 60-second PR check, and a hosted test for the bigger runs. For the broader strategy, see load testing in CI/CD and whether CLI tools are enough for CI/CD.

Pattern (a): k6 inside the runner

k6 is a good fit here: a single binary, JavaScript test scripts, and thresholds that set the process exit code. When any threshold fails, k6 run exits with code 99, which fails the step.

The test script

// tests/perf/smoke.js
import http from 'k6/http';
import { check, sleep } from 'k6';

const BASE_URL = __ENV.BASE_URL;

export const options = {
  scenarios: {
    smoke: {
      executor: 'constant-arrival-rate',   // fixed RPS, not closed-loop VUs
      rate: Number(__ENV.RATE || 20),      // iterations per second
      timeUnit: '1s',
      duration: __ENV.DURATION || '60s',
      preAllocatedVUs: 20,
      maxVUs: 100,
    },
  },
  thresholds: {
    http_req_failed: ['rate<0.01'],                     // < 1% errors
    http_req_duration: ['p(95)<400', 'p(99)<1000'],     // ms
    'http_req_duration{name:checkout}': [{ threshold: 'p(95)<800', abortOnFail: true }],
  },
};

export default function () {
  const list = http.get(`${BASE_URL}/api/products?limit=20`, { tags: { name: 'list' } });
  check(list, { 'list 200': (r) => r.status === 200 });

  const res = http.post(`${BASE_URL}/api/checkout/quote`,
    JSON.stringify({ sku: 'TEST-001', qty: 1 }),
    { headers: { 'Content-Type': 'application/json' }, tags: { name: 'checkout' } });
  check(res, { 'quote 200': (r) => r.status === 200 });
  sleep(0.5);
}

The constant-arrival-rate executor keeps the request rate fixed even if the server slows down, which avoids hiding latency the way a closed loop does (see coordinated omission).

The workflow

# .github/workflows/perf-smoke.yml
name: perf-smoke

on:
  pull_request:
    paths: ['src/**', 'tests/perf/**']

concurrency:
  group: perf-smoke-${{ github.event.pull_request.number }}
  cancel-in-progress: true          # a new push cancels the old run

permissions:
  contents: read

jobs:
  k6-smoke:
    runs-on: ubuntu-latest
    timeout-minutes: 10
    steps:
      - uses: actions/checkout@v4

      - uses: grafana/setup-k6-action@v1

      - name: Run k6 smoke test
        env:
          BASE_URL: ${{ vars.PREVIEW_BASE_URL }}
          RATE: '20'
          DURATION: '60s'
        run: k6 run --summary-export=summary.json tests/perf/smoke.js

      - name: Upload summary
        if: always()
        uses: actions/upload-artifact@v4
        with:
          name: k6-summary
          path: summary.json

Runner limits to respect

• Small VMs. Standard GitHub-hosted Linux runners are in the 2–4 vCPU class depending on repository visibility and plan. Larger runners exist at extra cost. If the runner's CPU is pegged, your latency numbers include the generator's own queueing.
• Shared network. Runners sit on shared cloud infrastructure with variable network paths and changing IP addresses. Run-to-run noise is higher than on dedicated hardware, so set gates with some margin and compare trends, not single runs.
• WAF and rate limits. Runner IPs come from large shared cloud ranges. A WAF may challenge them, and allowlisting is impractical. Test a staging host that is not behind bot protection, or use a self-hosted runner with a fixed egress IP.
• Time limits. Jobs on GitHub-hosted runners are capped at 6 hours, and you pay for every minute on private repos. Soak tests belong elsewhere.

Pattern (b): trigger a hosted test from the workflow

Here the workflow does not generate load. It authenticates to a hosted service, starts a saved test, and fails the job if the test breached its thresholds. The load comes from the provider's workers, so the runner size does not matter.

With LoadTester, API tokens for CI/CD are included in the Starter ($19/month) and Pro ($49/month) plans. Create a token in the app (tokens start with wst_), then add it as a repository secret named LOADTESTER_TOKEN under Settings → Secrets and variables → Actions. Save the test itself in the app with its thresholds (for example p95 < 400 ms and error rate < 2%, with auto-stop on breach), and make sure the target domain is verified.

To start the run, call the run endpoint documented on the API page in the app. The URL and response fields below are placeholders, not real paths; copy the actual ones from the API docs:

      - name: Trigger saved load test
        env:
          LOADTESTER_TOKEN: ${{ secrets.LOADTESTER_TOKEN }}
          # PLACEHOLDER: set this repository variable to the run endpoint
          # for your saved test, exactly as shown in the app's API docs.
          LOADTESTER_RUN_URL: ${{ vars.LOADTESTER_RUN_URL }}
        run: |
          curl --fail-with-body -sS -X POST "$LOADTESTER_RUN_URL" \
            -H "Authorization: Bearer $LOADTESTER_TOKEN" \
            -o run.json
          cat run.json

      - name: Gate on result
        run: |
          # PLACEHOLDER: wait for completion and read the pass/fail field
          # using the status mechanism described in the API docs, then:
          #   exit 1 if the thresholds were breached
          echo "See API docs for the status and result fields"

Two alternatives avoid polling from the workflow entirely: a scheduled (cron) test in the app with Slack or email alerts and regression notifications against a baseline, or a completion webhook pointed at your own endpoint. These work well for nightly runs where nobody is waiting on a PR.

Deploy markers with the annotations endpoint

When a longer test is running while you deploy (for example a scheduled 10-minute run against staging), a marker on the chart at the moment of the deploy makes cause and effect obvious. LoadTester has an annotations endpoint for this:

POST https://app.loadtester.org/api/annotations/push
Authorization: Bearer $LOADTESTER_TOKEN
Content-Type: application/json

{"test_id":"<uuid>","ts_seconds":45,"label":"Deploy v2.1"}

test_id is the UUID of the test, ts_seconds is where on the test's timeline the marker goes (seconds from the start), and label is the text shown on the chart. As a workflow step after your deploy job:

      - name: Push deploy marker
        if: success()
        env:
          LOADTESTER_TOKEN: ${{ secrets.LOADTESTER_TOKEN }}
          TEST_ID: ${{ vars.LOADTESTER_TEST_ID }}
          TEST_STARTED_AT: ${{ needs.start-test.outputs.started_at }}   # epoch seconds
        run: |
          TS=$(( $(date +%s) - TEST_STARTED_AT ))
          curl --fail-with-body -sS -X POST \
            https://app.loadtester.org/api/annotations/push \
            -H "Authorization: Bearer $LOADTESTER_TOKEN" \
            -H "Content-Type: application/json" \
            -d "{\"test_id\":\"$TEST_ID\",\"ts_seconds\":$TS,\"label\":\"Deploy ${GITHUB_SHA::7}\"}"

If the p95 line steps up right after the marker, you have your regression and the commit that caused it. The performance regression testing guide covers how to set the comparison baseline.

When to run: PR, main, nightly

on:
  push:
    branches: [main]
  schedule:
    - cron: '17 2 * * *'     # 02:17 UTC daily; avoid minute 0, which is busiest
  workflow_dispatch: {}       # manual runs with the same workflow

Schedules run in UTC, only from the default branch, and on a best-effort basis: they can start late when GitHub is busy. In public repositories, scheduled workflows are disabled automatically after 60 days without repository activity.

Concurrency, environments and secrets

One test per target at a time

Two load tests against the same staging environment at once produce two invalid results. Use a concurrency group keyed on the target, not the branch, and do not cancel a gate that is already running:

concurrency:
  group: loadtest-staging
  cancel-in-progress: false

This also keeps you within your provider's concurrent test limit (LoadTester Pro allows two concurrent tests; Free and Starter allow one).

Protect the environment

jobs:
  perf-gate:
    runs-on: ubuntu-latest
    environment: perf-staging     # environment-scoped secrets and rules
    timeout-minutes: 20

In Settings → Environments, restrict perf-staging to the main branch and store LOADTESTER_TOKEN there instead of at repository level. For anything that touches production, add required reviewers so a person approves each run.

Secrets hygiene

• Pass tokens through env: and reference them as shell variables, never inline ${{ secrets.X }} inside a script string that might be echoed.
• Pull requests from forks do not receive secrets. Do not "fix" that with pull_request_target plus a checkout of the PR head; that runs untrusted code with your token.
• Set permissions: contents: read at workflow level unless a job needs more.
• Rotate the token if a log ever shows it; GitHub masks registered secrets but not values derived from them.
